Spiral staircase outdoor TORONTO

SPIRAL STAIRCASE METAL SUITABLE FOR OUTDOORS

Take up very little room below
spiral staircase weather-resistant for outdoor use
No maintenance
Top-quality - treads in hot-dip galvanized perforated sheet steel
Our DOLLE TORONTO Spiral staircase is an ideal external access solution. All the components are hot dipped galvanised to ensure they with standard the elements. The treads are perforated plate ideal for safety and comfort even in the wet.
Read more

Configure your product

Accessories 2 products

Products with the pencil icon require your customization after being added them to the cart.
As low as  £1,499.99
Do you have any questions about this product?
Product description

Weather resistant outdoor spiral staircase

TORONTO Spiral staircase from DOLLE constructed in metal and suitable for both indoor and outdoor use. Designed for convenience, from the balcony or terrace to the garden! The staircase occupies the smallest of space! The DOLLE Toronto is the ideal solution! And can reach a floor height of up to 399cm in safety with its comfort perforated steel steps. The lowest height is 246cm, you can adjust the height to suit your project by using the spacers provided or removing a tread. The banister with round bars is hot dipped galvanised and finished with a rounded plastic handrail. DOLLE Toronto is available in 3 diameters 125, 155 and 185 cm.


MATCHING LANDING BANISTER

We offer a matching landing banister that will add the final touch, this is important for safety that the banister is 90cm high and has no gaps wider that 100mm. Just measure the length you need, first you will need a starter kit this is 1 metre long and will give you the components to join the banister to the staircase, then you can purchase as many 1 metre packs as you like. To give you an example, if you have 4 metres that’s simple that 1 starter then then 3 extension packs. If you have 3.8 metres, you can cut the second pack down to size. The landing banister will seamlessly flow from the staircase. You can see our range here landing banister.

As a safe basis, a foundation is necessary for the DOLLE Toronto. Plan the foundation at least 40 cm x 40 cm x 40 cm (L x W x D). This information corresponds to normal soil conditions. The stair can be used as left- or right turn and can be used for square or round openings that need to be cut 10cm wider that the width of the staircase you choose. This base spiral staircase kit comes with 11 treads up to 15 treads just choose your floor height from the drop-down menu.

Child proof your staircase by adding riser bars. These will close the gap between the tread for added safety.

If you want to know more about the specifications, you can visit technical data and downloads section to find out more. There is also a video section where you can view a full installation video, this shows the build process from start to finish. It will also give you an insight into the quality of the components we supply.

To ensure the highest quality we manufacture all our staircase to specific standards. All DOLLE spiral staircases complies with European building standards defined in EN 1991 and EN 1993. The staircase TORONTO staircase is certified to a maximum point load of 200 kg and a maximum total load of 620 kg. The banister railing is also approved for a horizontal load of 50 kg metre.

Technical data
Product number Please select a variant
Internal product number Please select a variant
EAN Please select a variant
Floor opening min. length Please select a variant
Floor opening min. width Please select a variant
Floor-to-floor height Please select a variant
Type Spiral
Diameter Please select a variant
Distance between balusters/fillings Please select a variant
Building reg. compliant Yes
Tread rise From 20,5 to 23,5 cm per tread (depending on floor-to-floor height)
Tread thickness Please select a variant
Treads width Please select a variant
Tread material Metal, perforated
Tread finish Hot galvanized according to EN ISO 1461:2009
Number of treads Please select a variant
Number of risers Please select a variant
Structure material Steel
Structure finish Hot galvanized according to EN ISO 1461:2009
Handrail material PVC
Handrail diameter 40 mm
Banister height 90 - 92.5 cm
Banister variant Please select a variant
Tread colour Please select a variant
Colour of structure Grey metallic
