Staircase ATLANTA
THE ULTIMATE SPACE SAVING STAIRCASE
Easy to assemble in one day
Strong and stable
Simple and minimalistic design
FSC® certified wood
The DOLLE ATLANTA straight flight staircase was designed specifically for restricted spaces. The staircase features 11 multiplex treads, also available are a full range of accessories to enhance the style and safety of your staircase. Design stair below.
Read more
As low as
£999.99
As low as
Product description
Tight space? See if this DOLLE staircase could be the solution.
An ingenious tread shape makes this staircase a real space-saver! The ATLANTA staircase comes with 11 multiplex beech steps taking up a small footprint in the room, its only 137 cm in length when fitted. One or more treads can be removed if you do not need the maximum floor-to-floor height of 300 cm, meaning the staircase can also be adjusted for a range of lower landing heights. Each tread has an adjustable rise of between 19 and 25 cm. The Handrail banister maximises both comfort and stability even on a space saving staircase.
Simple, modular structural elements and a straight PVC handrail ensure easy installation. Varnished treads, powder-coated steel structural elements in a range of colour options and a UV-resistant PVC handrail add up to a strong and durable staircase which is built to last.
The ATLANTA staircase comes in a choice of modern colours with a semi-gloss finish. Pick the design that matches your needs and interior. Included in the package you get DOLLE top cover and DOLLE foot cover – designed to hide screws and assemblies on our modular staircases.
The ATLANTA staircase is available in a choice of modern colours with a semi-gloss finish. Pick the design that matches your exact needs and interior style. Included in the package are DOLLE top cover and DOLLE foot covers, these are designed to hide fixings for a clean finish on our modular staircases. Uncompromising safety and convenience
We don’t compromise safety for convenience
ATLANTA is a strong, stable staircase. Certified compliance with the load requirements defined in European building regulations (EUROCODE) ensure we supply only high quality, safe staircases.
ATLANTA can be configured with extra vertical middle handrail balusters. This will reduce the gap between vertical balusters from 20.5 cm to 9 cm adding even greater safety and comfort. This will also be a UK building regulations requirement if you intend to use your ATLANTA staircase as a main stair. Select the ATLANTA configuration with 2 vertical balusters per tread from the drop-down menu above. To enhance child safety, you can add a second banister this is ideal if you intend to install your staircase centrally rather than up against a wall. You can also install riser bars under the treads in colours to match the staircase, this will close the gap making the staircase safer and comfortable to climb. And finally to finish your project you can add a matching landing banister to safely secure your landing space.
Will it fit? Check out the staircase dimensions
Go to our Measurement guide to learn how to measure your room for a staircase.
In our Dimensions you will find precise measurements of the staircase and explanation of staircase terminology.
Be aware this staircase is designed for rooms with a deck thickness of min. 20 cm. (rise + 2 cm).
Not sure and want to make sure everything is correct for your project? Just get in contact and we can help.
ATLANTA tread
Technical data
|
M
|
137 cm |
|---|---|
|
N
|
69 cm |
|
H
|
Please select a variant |
|
R
|
Please select a variant |
|
R1
|
Please select a variant |
|
C1
|
62 cm |
|
S
|
From 19,0 to 25,0 cm per tread (depending on floor-to-floor height) |
|
G
|
11.5 cm |
| Product number | Please select a variant |
| Internal product number | Please select a variant |
| Opening length | 137 cm |
| Opening width | 69 cm |
| Max. floor-to-floor height | 300 cm |
| Total going length | Please select a variant |
| Total going width | Please select a variant |
| Type | Straight flight (Paddle tread) |
| Staircase width | 62 cm |
| Tread rise | From 19,0 to 25,0 cm per tread (depending on floor-to-floor height) |
| Number of risers | 12 |
| Number of treads | 11 |
| Tread material | Please select a variant |
| Tread finish | Please select a variant |
| Tread thickness | 35 mm |
| Tread width | 58 cm |
| Tread depth | Please select a variant |
| Going | 11.5 cm |
| String material | Please select a variant |
| String finish | Please select a variant |
| Distance between balusters/fillings | Please select a variant |
| Handrail material | PVC |
| Use | Indoor use, Private use in single family homes |
| Maximum load | Certified to a max. point load of 200 kg., The banister railing is approved for a horizontal load of 50 kg / meter., Certified to a max. total load of 400 kg. |
